BARTEC GUA Junction & Pulling Box

The BARTEC GUA Junction & Pulling Box provides a compact and robust solution for electrical connections and cable routing in hazardous areas. Designed for Zone 1 and Zone 2 gas environments and Zone 21 and Zone 22 dust environments, the GUA range is suited to demanding industrial electrical installations.

Manufactured from marine-grade copper-free aluminium, with AISI 316L stainless steel available for selected sizes, the GUA range combines durable construction with IP66 ingress protection. Ex d IIC and Ex e IIC executions are available, providing flexibility for different hazardous area installation requirements.

The GUA range is available in multiple sizes and hub arrangements, with two, three, four and five-entry configurations available depending on the model. Hub sizes range from 1/2″ to 2″, providing a versatile solution for cable pulling, branching and electrical connections in hazardous area installations.

Key features

• Hazardous area junction and pulling box
• Ex d IIC and Ex e IIC executions available
• Suitable for Zone 1 and Zone 2 gas hazardous areas
• Suitable for Zone 21 and Zone 22 dust hazardous areas
• IP66 ingress protection
• Marine-grade copper-free aluminium construction
• AISI 316L stainless steel available for selected sizes
• Stainless steel screws
• NBR O-ring sealing
• Ambient temperature range up to -60°C to +130°C, depending on configuration
• Multiple hub arrangements available
• Hub sizes from 1/2″ to 2″
• ATEX and IECEx certified
• Internal anti-condensation coating available on request
• External epoxy coating available on request
• Cast iron construction available on request
